Identify Anti-Patterns in SQL Server Queries

Problem

How can we capture queries that are causing issues and stopping the query optimizer from working efficiently? SQL Server 2022 introduces a new extended event for this purpose. In this article, we look at a new SQL Server Extended Event to help identify anti-patterns in SQL queries​ and improve performance.

Solution

Extended events are great for capturing and troubleshooting SQL Server performance issues. This tip discusses a valuable new extended event introduced in SQL Server 2022, the Query_AntiPattern Extended Event.

In general, the SQL Server query optimizer devises several execution plans and chooses the lowest-cost optimized plan to execute a query. Sometimes, however, it cannot optimize the plan, which might lead to insufficient resource utilization despite proper indexing and statistics.

Examples of the issues that may lead to inefficient query plans are:

• Non-Sargable Queries
• Parameter Sniffing Issues
• Implicit Data Type Conversions
• Missing or Outdated Statistics
• Over-Indexing or Under-Indexing
• Complex Joins and Subqueries
• Low-Selectivity Filters

SQL Server 2022 introduced a new extended event to capture queries that are having these issues and causing the query optimizer to not work efficiently.

Query_AntiPattern Extended Event

The extended event query_antipattern captures insufficient query patterns in your workload that lead to performance issues. Once identified, you can modify your query to avoid antipatterns and help SQL Server optimize the code.

Querying sys.dm_xe_map_values gives the values used in the query antipattern extended event.

SELECT name,map_value
FROM sys.dm_xe_map_values
WHERE name = N'query_antipattern_type';

LargeIn

A large number of values in the IN clause can be resource-intensive for large datasets. The query optimizer might need to use an index scan instead of a seek. Here is an example.

SELECT * FROM tableA WHERE [column_name] IN (1, 2, 3, ..., N);

LargeNumberOfOrInPredicate

It checks for multiple OR clauses or large IN predicates in the where clause, like below. The query optimizer must evaluate each OR condition, leading to intensive scans and performance issues for large tables or rows.

SELECT * FROM tableA WHERE [column_name] = 1 OR[column_name] = 2 OR ... OR[column_name] = N;

MAX

Queries using aggregate functions, such as MAX, may perform slowly without appropriate indexes. If you are trying to fetch the maximum value from a non-indexed column, the query optimizer may perform a scan, which can be a bottleneck for tables with a large number of rows.

NonOptimalOrLogic

As the name suggests, this term refers to using poorly optimized OR clauses like LargeNumberOfOrInPredicate.

TypeConvertPreventingSeek

You might have seen implicit conversion warnings in the SQL Server execution plan.

CREATE TABLE ImplicitConversionTest (    ID INT PRIMARY KEY,
    ColumnA VARCHAR(50)
);
INSERT INTO ImplicitConversionTest (ID, ColumnA)
VALUES (1, '100'), (2, '200'), (3, '300');
Go

SELECT *
FROM ImplicitConversionTest
WHERE ColumnA = 100;

Below is the actual execution plan of the selected statement above and we can see convert implicit warnings.

In the above query, column A’s data type is NVARCHAR, but we are comparing it with the integer value in the select statement. Due to this data type difference, SQL Server needs to do an implicit conversion. The execution plan displays a warning that the implicit conversion might affect the cardinality estimation in the query plan choice and ultimately cause performance impact.

Configuring the Query_AntiPattern Extended Event

The Query_AntiPattern extended event is available in the following:

• Category: Warnings
• Channel: Operational
• Package: sqlserver

You can use the extended event wizard in SQL Server Management Studio (SSMS) or the following query to set it up with required fields, such as client_app_name, plan_handle, query_hash, query_plan_hash, and sql_text.

USE master;
GO

IF EXISTS (SELECT *
           FROM   sys.dm_xe_sessions
           WHERE  NAME = 'antipattern_identify')
  BEGIN
      DROP event session [antipattern_identify] ON server;
  END
GO

CREATE EVENT SESSION [antipattern_identify] ON SERVER
     ADD EVENT sqlserver.query_antipattern (
        ACTION(sqlserver.client_app_name,sqlserver.plan_handle,
               sqlserver.query_hash,sqlserver.query_plan_hash,
               sqlserver.sql_text)
          ) ADD TARGET package0.ring_buffer(SET max_memory=(500))
GO

After setting up the extended event, start it with the ALTER EVENT SESSION command to find and identify anti-patterns in SQL queries.

ALTER EVENT SESSION antipattern_identify ON SERVER
STATE = START;
GO

This extended event session is viewable in the SSMS, as shown below.

Right-click on the antipattern_identify extended event and click on Watch Live Data.

Capture Bad Queries with the Extended Event

Let’s run a few sample queries and see how it gets the data.

USE WideWorldImporters
GO

SELECT *
FROM   Sales.Orders
WHERE  CustomerPurchaseOrderNumber = 16374;

As shown below, the extended event captured the TypeConvertPreventingSeek extended event. The query is looking to search a specific record. However, due to this implicit conversion, the query optimizer used an index scan.

We can see the data the data below that was captured with the Extended Event.

Let’s run another query that contains around 500 values in the IN expression of the WHERE clause.

SELECT *
FROM Sales.Orders
WHERE CustomerPurchaseOrderNumber IN (
    1, 2, 3, 4, 5, 6, 7, 8, 9, 10,
    11, 12, 13, 14, 15, 16, 17, 18, 19, 20,
    21, 22, 23, 24, 25, 26, 27, 28, 29, 30,
    31, 32, 33, 34, 35, 36, 37, 38, 39, 40,
    41, 42, 43, 44, 45, 46, 47, 48, 49, 50,
    51, 52, 53, 54, 55, 56, 57, 58, 59, 60,
    61, 62, 63, 64, 65, 66, 67, 68, 69, 70,
    71, 72, 73, 74, 75, 76, 77, 78, 79, 80,
    81, 82, 83, 84, 85, 86, 87, 88, 89, 90,
    91, 92, 93, 94, 95, 96, 97, 98, 99, 100,
    101, 102, 103, 104, 105, 106, 107, 108, 109, 110,
    111, 112, 113, 114, 115, 116, 117, 118, 119, 120,
    121, 122, 123, 124, 125, 126, 127, 128, 129, 130,
    131, 132, 133, 134, 135, 136, 137, 138, 139, 140,
    141, 142, 143, 144, 145, 146, 147, 148, 149, 150,
    151, 152, 153, 154, 155, 156, 157, 158, 159, 160,
    161, 162, 163, 164, 165, 166, 167, 168, 169, 170,
    171, 172, 173, 174, 175, 176, 177, 178, 179, 180,
    181, 182, 183, 184, 185, 186, 187, 188, 189, 190,
    191, 192, 193, 194, 195, 196, 197, 198, 199, 200,
    201, 202, 203, 204, 205, 206, 207, 208, 209, 210,
    211, 212, 213, 214, 215, 216, 217, 218, 219, 220,
    221, 222, 223, 224, 225, 226, 227, 228, 229, 230,
    231, 232, 233, 234, 235, 236, 237, 238, 239, 240,
    241, 242, 243, 244, 245, 246, 247, 248, 249, 250,
    251, 252, 253, 254, 255, 256, 257, 258, 259, 260,
    261, 262, 263, 264, 265, 266, 267, 268, 269, 270,
    271, 272, 273, 274, 275, 276, 277, 278, 279, 280,
    281, 282, 283, 284, 285, 286, 287, 288, 289, 290,
    291, 292, 293, 294, 295, 296, 297, 298, 299, 300,
    301, 302, 303, 304, 305, 306, 307, 308, 309, 310,
    311, 312, 313, 314, 315, 316, 317, 318, 319, 320,
    321, 322, 323, 324, 325, 326, 327, 328, 329, 330,
    331, 332, 333, 334, 335, 336, 337, 338, 339, 340,
    341, 342, 343, 344, 345, 346, 347, 348, 349, 350,
    351, 352, 353, 354, 355, 356, 357, 358, 359, 360,
    361, 362, 363, 364, 365, 366, 367, 368, 369, 370,
    371, 372, 373, 374, 375, 376, 377, 378, 379, 380,
    381, 382, 383, 384, 385, 386, 387, 388, 389, 390,
    391, 392, 393, 394, 395, 396, 397, 398, 399, 400,
    401, 402, 403, 404, 405, 406, 407, 408, 409, 410,
    411, 412, 413, 414, 415, 416, 417, 418, 419, 420,
    421, 422, 423, 424, 425, 426, 427, 428, 429, 430,
    431, 432, 433, 434, 435, 436, 437, 438, 439, 440,
    441, 442, 443, 444, 445, 446, 447, 448, 449, 450,
    451, 452, 453, 454, 455, 456, 457, 458, 459, 460,
    461, 462, 463, 464, 465, 466, 467, 468, 469, 470,
    471, 472, 473, 474, 475, 476, 477, 478, 479, 480,
    481, 482, 483, 484, 485, 486, 487, 488, 489, 490,
    491, 492, 493, 494, 495, 496, 497, 498, 499, 500
);

Execute the query and switch to the watch live data window. As shown below, it generates an error for query_antipattern – LargeNumberOfOrInPredicate.

Similarly, if we rewrite the above query using the OR operator, it raises the LargeNumberOfOrInPredicate warning as well in the query_antipatten extended event.

SELECT *
FROM Sales.Orders
WHERE CustomerPurchaseOrderNumber = 1
OR CustomerPurchaseOrderNumber = 2 OR CustomerPurchaseOrderNumber = 3 OR CustomerPurchaseOrderNumber  = 4 OR CustomerPurchaseOrderNumber  = 5
OR CustomerPurchaseOrderNumber = 6 OR CustomerPurchaseOrderNumber  = 7 OR CustomerPurchaseOrderNumber  = 8 OR CustomerPurchaseOrderNumber  = 9
OR CustomerPurchaseOrderNumber  = 10 OR CustomerPurchaseOrderNumber  = 11 OR CustomerPurchaseOrderNumber  = 12 OR CustomerPurchaseOrderNumber  = 13
OR CustomerPurchaseOrderNumber  = 14 OR CustomerPurchaseOrderNumber  = 15 OR CustomerPurchaseOrderNumber  = 16 OR CustomerPurchaseOrderNumber  = 17
OR CustomerPurchaseOrderNumber  = 18 OR CustomerPurchaseOrderNumber  = 19 OR CustomerPurchaseOrderNumber  = 20 OR CustomerPurchaseOrderNumber  = 21
OR CustomerPurchaseOrderNumber  = 22 OR CustomerPurchaseOrderNumber  = 23 OR CustomerPurchaseOrderNumber  = 24 OR CustomerPurchaseOrderNumber  = 25
OR CustomerPurchaseOrderNumber  = 26 OR CustomerPurchaseOrderNumber  = 27 OR CustomerPurchaseOrderNumber  = 28 OR CustomerPurchaseOrderNumber  = 29
OR CustomerPurchaseOrderNumber  = 30 OR CustomerPurchaseOrderNumber  = 31 OR CustomerPurchaseOrderNumber  = 32 OR CustomerPurchaseOrderNumber  = 33
OR CustomerPurchaseOrderNumber  = 34 OR CustomerPurchaseOrderNumber  = 35 OR CustomerPurchaseOrderNumber  = 36 OR CustomerPurchaseOrderNumber  = 37
OR CustomerPurchaseOrderNumber  = 38 OR CustomerPurchaseOrderNumber  = 39 OR CustomerPurchaseOrderNumber  = 40 OR CustomerPurchaseOrderNumber  = 41
OR CustomerPurchaseOrderNumber  = 42 OR CustomerPurchaseOrderNumber  = 43 OR CustomerPurchaseOrderNumber  = 44 OR CustomerPurchaseOrderNumber  = 45
OR CustomerPurchaseOrderNumber  = 46 OR CustomerPurchaseOrderNumber  = 47 OR CustomerPurchaseOrderNumber  = 48 OR CustomerPurchaseOrderNumber  = 49
OR CustomerPurchaseOrderNumber  = 50 OR CustomerPurchaseOrderNumber  = 51 OR CustomerPurchaseOrderNumber  = 52 OR CustomerPurchaseOrderNumber  = 53
OR CustomerPurchaseOrderNumber  = 54 OR CustomerPurchaseOrderNumber  = 55 OR CustomerPurchaseOrderNumber  = 56 OR CustomerPurchaseOrderNumber  = 57
OR CustomerPurchaseOrderNumber  = 58 OR CustomerPurchaseOrderNumber  = 59 OR CustomerPurchaseOrderNumber  = 60 OR CustomerPurchaseOrderNumber  = 61
OR CustomerPurchaseOrderNumber  = 62 OR CustomerPurchaseOrderNumber  = 63 OR CustomerPurchaseOrderNumber  = 64 OR CustomerPurchaseOrderNumber  = 65
OR CustomerPurchaseOrderNumber  = 66 OR CustomerPurchaseOrderNumber  = 67 OR CustomerPurchaseOrderNumber  = 68 OR CustomerPurchaseOrderNumber  = 69
OR CustomerPurchaseOrderNumber  = 70 OR CustomerPurchaseOrderNumber  = 71 OR CustomerPurchaseOrderNumber  = 72 OR CustomerPurchaseOrderNumber  = 73
OR CustomerPurchaseOrderNumber  = 74 OR CustomerPurchaseOrderNumber  = 75 OR CustomerPurchaseOrderNumber  = 76 OR CustomerPurchaseOrderNumber  = 77
OR CustomerPurchaseOrderNumber  = 78 OR CustomerPurchaseOrderNumber  = 79 OR CustomerPurchaseOrderNumber  = 80 OR CustomerPurchaseOrderNumber  = 81
OR CustomerPurchaseOrderNumber  = 82 OR CustomerPurchaseOrderNumber  = 83 OR CustomerPurchaseOrderNumber  = 84 OR CustomerPurchaseOrderNumber  = 85
OR CustomerPurchaseOrderNumber  = 86 OR CustomerPurchaseOrderNumber  = 87 OR CustomerPurchaseOrderNumber  = 88 OR CustomerPurchaseOrderNumber  = 89
OR CustomerPurchaseOrderNumber  = 90 OR CustomerPurchaseOrderNumber  = 91 OR CustomerPurchaseOrderNumber  = 92 OR CustomerPurchaseOrderNumber  = 93
OR CustomerPurchaseOrderNumber  = 94 OR CustomerPurchaseOrderNumber  = 95 OR CustomerPurchaseOrderNumber  = 96 OR CustomerPurchaseOrderNumber  = 97
OR CustomerPurchaseOrderNumber  = 98 OR CustomerPurchaseOrderNumber  = 99 OR CustomerPurchaseOrderNumber  = 100 OR CustomerPurchaseOrderNumber  = 101
OR CustomerPurchaseOrderNumber  = 102 OR CustomerPurchaseOrderNumber  = 103 OR CustomerPurchaseOrderNumber  = 104 OR CustomerPurchaseOrderNumber  = 105
OR CustomerPurchaseOrderNumber  = 106 OR CustomerPurchaseOrderNumber  = 107 OR CustomerPurchaseOrderNumber  = 108 OR CustomerPurchaseOrderNumber  = 109
OR CustomerPurchaseOrderNumber  = 110 OR CustomerPurchaseOrderNumber  = 111 OR CustomerPurchaseOrderNumber  = 112 OR CustomerPurchaseOrderNumber  = 113
OR CustomerPurchaseOrderNumber  = 114 OR CustomerPurchaseOrderNumber  = 115 OR CustomerPurchaseOrderNumber  = 116 OR CustomerPurchaseOrderNumber  = 117
OR CustomerPurchaseOrderNumber  = 118 OR CustomerPurchaseOrderNumber  = 119 OR CustomerPurchaseOrderNumber  = 120 OR CustomerPurchaseOrderNumber  = 121
OR CustomerPurchaseOrderNumber  = 122 OR CustomerPurchaseOrderNumber  = 123 OR CustomerPurchaseOrderNumber  = 124 OR CustomerPurchaseOrderNumber  = 125
OR CustomerPurchaseOrderNumber  = 126 OR CustomerPurchaseOrderNumber  = 127 OR CustomerPurchaseOrderNumber  = 128 OR CustomerPurchaseOrderNumber  = 129
OR CustomerPurchaseOrderNumber  = 130

Exclude SSMS IntelliSense Queries

While I was testing this extended event, in addition to the queries that I was running, it also captured queries with the client_app_name as Microsoft SQL Server Management Studio—Transact-SQL IntelliSense. These are queries executed by the SSMS IntelliSense. It is better to exclude these to get better results.

The following query alters the extended events to exclude the SSMS intelligence. To take this change into effect, you need to stop and start the extended event session.

ALTER EVENT SESSION [antipattern_identify] ON SERVER
DROP EVENT sqlserver.query_antipattern

ALTER EVENT SESSION [antipattern_identify] ON SERVER
ADD EVENT sqlserver.query_antipattern(
    ACTION(sqlserver.client_app_name,sqlserver.plan_handle,sqlserver.query_hash,sqlserver.query_plan_hash,sqlserver.sql_text)
    WHERE ([sqlserver].[client_app_name]<>N'Microsoft SQL Server Management Studio - Transact-SQL IntelliSense'))
GO

Next Steps

• Once you identify anti-patterns in SQL queries​, you can work on these individual queries and fix the underlying issues.
• Read about the new functions in SQL Server 2022 in the tecnical documentation.
• Go through existing SQL Server 2022 tips.
